Laser Transmitting Music

Start with the video, then use the science notes and recommended parts below to follow the idea behind the build.

Radio & soundOpticsAudio

Watch on YouTube

How it works

What this project is testing.

Light can carry an audio signal the same way radio can. If the laser brightness is varied with music, a light sensor can turn those brightness changes back into voltage.

Read more

This experiment demonstrates optical communication: the beam is the link, and line-of-sight alignment matters because the message is literally riding on changing light intensity.

P_{l i g h t} (t) = P_{0} [1 + m x (t)]

The audio signal changes the laser light power around a steady average level.

I_{p h o t o} \propto P_{l i g h t}

A photodetector or solar cell produces more current when more light hits it.
