Start with the video, then use the science notes and recommended parts below to follow the idea behind the build.

High voltageBuild

Watch on YouTube

How it works

What this project is testing.

A capacitor stores energy by separating charge across an insulating layer. High voltage makes that stored field stronger, which is useful for demos but also why capacitors can remain dangerous after power is removed.

Read more

The experiment demonstrates what sets capacitance and voltage limits: plate area, spacing, dielectric material, and the point where the insulator finally breaks down.

C = ε \frac{A}{d}

Capacitance increases with plate area and dielectric strength, and decreases as plate spacing grows.

U = \frac{1}{2} C V^{2}

Stored energy rises with capacitance and with the square of voltage.
