AC to DC converter

Start with the video, then use the science notes and recommended parts below to follow the idea behind the build.

ElectricityBuildElectronics

Watch on YouTube

How it works

What this project is testing.

Wall power alternates direction, but many electronics need current that mostly flows one way. An AC-to-DC converter reshapes that back-and-forth waveform into a one-direction output.

Read more

The experiment demonstrates rectification and smoothing: first flip or block the negative half of the wave, then use stored charge to fill in the dips.

V_{D C} \approx V_{p e ak} - 2 V_{D}

A bridge rectifier output is roughly the peak AC voltage minus two diode drops.

Δ V \approx \frac{I _{l o a d}}{f _{r i ppl e} C}

A larger capacitor or lighter load reduces ripple in the smoothed output.
