1000 Amp Transformer

Start with the video, then use the science notes and recommended parts below to follow the idea behind the build.

High voltageBuildRadio

Watch on YouTube

How it works

What this project is testing.

A transformer can trade voltage for current. With only a few turns on the output side, the voltage drops, but the available current can become enormous.

Read more

This experiment demonstrates magnetic coupling and power tradeoff. The dramatic part is not free energy; it is the way a changing magnetic field lets one coil push energy into another coil at a very different voltage-current balance.

\frac{V _{s}}{V _{p}} = \frac{N _{s}}{N _{p}}

The secondary voltage follows the ratio of wire turns between the two coils.

V_{p} I_{p} \approx V_{s} I_{s}

In an ideal transformer, power is roughly conserved, so lower voltage can mean much higher current.
