Solar panel made of LEDs

Start with the video, then use the science notes and recommended parts below to follow the idea behind the build.

ElectricityBuildElectronics

Watch on YouTube

How it works

What this project is testing.

An LED can work in reverse. Usually electricity goes in and light comes out; shine enough light on the junction and it can produce a small voltage and current.

Read more

This experiment demonstrates the photovoltaic effect and the tradeoff between voltage and current when LEDs are arranged together.

E_{γ} = \frac{h c}{λ}

Shorter-wavelength light carries more energy per photon, which matters for freeing charge in a junction.

P = I V

The useful electrical power is voltage times current, usually tiny for LEDs used this way.
