Cathode Ray

Start with the video, then use the science notes and recommended parts below to follow the idea behind the build.

Science

Watch on YouTube

How it works

What this project is testing.

A cathode ray tube makes electrons visible. In a low-pressure tube, high voltage pulls electrons away from the cathode and sends them across the glass where the beam can glow.

Read more

The experiment demonstrates that the ray is made of charged particles, not just light. Bring a magnet nearby and the beam bends because moving charges feel a sideways magnetic force.

F = q v \times B

A magnetic field pushes moving charged particles sideways.

\frac{1}{2} m v^{2} \approx e V

Voltage gives electrons kinetic energy as they accelerate through the tube.
