FM Transmitter

Start with the video, then use the science notes and recommended parts below to follow the idea behind the build.

Radio & soundBuildRadio

Watch on YouTube

How it works

What this project is testing.

An FM transmitter turns sound into tiny changes in radio frequency. The wave keeps about the same strength, but its spacing compresses and stretches with the audio.

Read more

This demonstrates why FM is good at rejecting noise: random amplitude bumps matter less when the message lives mostly in frequency changes.

f (t) = f_{c} + Δ f x (t)

The instant-by-instant carrier frequency shifts around f_c in proportion to the audio signal.
