Signal build

AM transmitter

Start with the video, then use the science notes and recommended parts below to follow the idea behind the build.

Radio & soundBuildRadio

Watch on YouTube

How it works

What this project is testing.

AM radio works by hiding sound inside a much faster wave. The carrier wave is the thing a radio can tune to; the audio rides along by changing the carrier height.

Read more

This build demonstrates resonance and modulation. A tuned system selects a carrier frequency, then the transmitter changes the amplitude so a nearby AM radio can recover the voice or music from the envelope.

f_{0} = \frac{1}{2 π L C}

An LC resonator naturally favors one radio frequency.

s (t) = A_{c} [1 + m a (t)] cos (2 π f_{c} t)

Amplitude modulation changes the carrier strength according to the audio signal.
